Features:

Combined relay and status - combines command relay and fan/pump status sensor in a single, easy-to-install unit
Fan and pump status - detect belt loss and motor failure ideal for fan and pump status
Polarity insensitive status outputs - fast and easy installation
Two outputs - H948 feature a SPDT command relay control two outputs with a single relay
Added flexibility - bracket on H958 can be installed in three different configurations
Easy setup - relay and status LEDs
Induced from monitored conductor sensor power

Specifications:

Manufacturer: Veris Industries
Manufacturer Part Number: H-958
Product Type: Current Switch
Coil Voltage: 12 VDC
Frequency Rating: 50/60 Hz
Current Measurement Rating: 2.5-135 A
Temperature Rating: 5 to 140 Degrees F
Operating Humidity: 10 to 90% RH
Electrical Wiring Size: 24-14 AWG
Mounting: Split Core
Switch Type: SPST
Dimensions: 4.0" x 5.95" x 1.75"
Weight: 0.38 lb.
